100 foot Bundle. Terminated with AC ends, 3 x BNC, Ethercon connector.
Our lightweight thinner diameter 3 SDI Version of the VILLAGE RUNNER cable. This version does not have the audio connectors found in our 2 SDI and 4 SDI cable but we have creative solutions for you! Using an audio balun on the ethernet line solves the need for audio conductors while an AC ethernet line adapter handles ethernet for streaming.
Super Flexible Rubber Jacketed Village Runner(tm) VR-3036a cable with 3 (Red, Blue and Green) 6G Coaxial lines, Cat6A and 3 18 GA Power conductors.
6G tested to 175 feet 12G tested to 100 Feet
Please CALL or Email sales@nebtek.com to order. We need to manually calculate price and shipping costs for this product. Thanks. Custom lengths available!
Each Rubber Jacketed Village Runner VR-3036a cable contains
3 (Red, Blue and Green) 6G Coaxial lines, Cat6A and 3 18 GA Power conductors.
6G tested to 175 feet 12G tested to 100 Feet
Flexible battle tested cable for video village and receiver/ap runs
Final Cable Diameter: 0.519" for 3 SDI lines
|
Video: 6G 24 AWG Coaxial Cables ( versions with 2 , 3 or 4 SDI coax available )
Conductor 24 AWG, solid bare copper
Foil Shield: Aluminium-Mylar-Aluminium
Braid Shield: 36 AWG tinned copper braid,
6G tested to 175 feet 12G tested to 100 Feet
|
Cat6e Cable (Quabbin)
Conductors 24 AWG, 7/34 tinned copper, Insulated
Individual conductors twisted into four pairs and cabled together
overall binder, drain wire, foil shield and Black PVC Jacket |
|
Power Three 18 AWG Insulated Conductors
Conductor 18 AWG, 18/3 tinned copper
Insulation PVC
|
Please CALL or Email sales@nebtek.com to order. We need to manually calculate price and shipping costs for this product. Thanks!
